Flow Meter Test Bench Design: Gravimetric Automated Weight System Configurations
Quick Answer: A gravimetric automated weight system uses a weigh tank and load cells to give direct flow reference values. It is the preferred bench design for liquid flow meters from DN15 to DN150 where total uncertainty below 0.2 percent is required. Silver Automation Instruments supplies the flow meters, pressure transmitters, and paperless recorders that integrate into these automated benches.
What Gravimetric Automated Weight System Configurations Cover
In practice, a flow meter test bench is a closed loop. It includes a supply tank, pump, filtration, pressure control, a test section, a reference measurement device, and a return path. In a gravimetric bench, the reference is a scale. The scale weighs fluid collected over a measured time. Flow rate equals mass divided by time after density correction.
Most benches use static weighing, dynamic weighing, or a hybrid master meter plus gravimetric system. Many production benches use the hybrid design because it shortens cycle time. Silver Automation Instruments supplies flow meters and transmitters for hybrid benches in Southeast Asia and the Middle East.
Key Components and Instrumentation
A DN50 water bench at a pump manufacturer in Vietnam used a 15 kW centrifugal pump, a 3000 L stainless steel supply tank, a pneumatic diverter, and two 150 kg load cells. The tested devices were Silver Instruments electromagnetic flow meters. Each meter produced 4-20 mA HART and pulse output. The PLC compared pulse totalizer values to the weighed mass every 60 seconds.
Temperature correction matters. A PT100 in the supply line and another in the weigh tank reduced water density error. Pressure transmitters monitored upstream pressure at 2 bar to 8 bar. Flow rates ranged from 1 m3/h to 40 m3/h. The customer required total uncertainty better than 0.2 percent for billing meters in Ho Chi Minh City.
How the Test Sequence Works
The PLC first sets pump speed and opens the fill valve. The flow meter under test reaches a stable setpoint. The diverter shifts toward the weigh tank. The timer starts. After a preset volume or mass, the diverter returns to the circulation line. The scale settles. The PLC records gross mass, net mass, fill time, average flow, density, line temperature, and meter pulse count. It then drains the tank and runs the next point.
Automated systems usually test five to ten flow points. Common points are 10, 25, 50, 75, and 100 percent of full scale. A sequence can take 45 minutes for a DN25 flow meter with five points. A master meter hybrid can cut that to 20 minutes because only check points need weigh cycles.
Configuration by Line Size and Accuracy Class
For DN15 to DN40 low flow applications such as diesel additives or edible oil dosing, a 30 kg to 100 kg bench scale is enough. Load cell resolution should be 0.1 g or 1 g. Silver Instruments Coriolis mass flow meters can serve as master references for these small lines. They measure mass flow directly in kg/h and remove some density correction steps.
For DN50 to DN150 water and chemical lines, a 600 kg to 1500 kg weigh tank is common. The bench should include a closed tank to reduce evaporation and a drain pump sized for at least twice the test flow. In a desalination plant in Oman, a DN100 seawater bench used a 1000 kg tank and a duplex strainer. Silver Automation Instruments supplied an electromagnetic flow meter with PTFE liner and 4-20 mA HART output for the raw water line.
For DN200 and above, a gravimetric system gets expensive. A master meter or clamp-on ultrasonic flow meter is often more practical. Silver Automation Instruments ultrasonic flow meters have been used on DN250 to DN400 water return lines where a large weigh bridge was not justified in a first phase.
Sizing a Bench for Your Flow Meter Line
Do not start with
_600x400.jpg)
The pump should deliver at least 20 percent more head than the worst case pressure drop. The divert valve should complete travel in less than 200 ms for high accuracy. The load cell or scale should be isolated from pump vibration. The PLC should timestamp all signals within 10 ms. This is where siloed instruments fail on site.
Common Mistakes on Customer Sites
Here is the thing. Many test bench issues are not caused by the flow meter. They come from air pockets, unstable water temperature, or a diverter that leaks. A paint manufacturer in Southeast Asia had a DN40 oval gear flow meter reading 2 percent high during commissioning. The root cause was a pump bypass valve that allowed small return flow during the weigh cycle. Silver Instruments reviewed the 4-20 mA signal and pulse data to confirm the meter was stable. The problem was in the bench piping.
Model Pairing for Test Bench Instruments
Silver Automation Instruments recommends different flow meters for different bench duties. For mass reference on liquid chemicals and oils, use a Coriolis mass flow meter with density output. For conductive water lines, use an electromagnetic flow meter with PTFE or hard rubber liner. For non conductive hydrocarbons or demineralized water, use an oval gear flow meter or ultrasonic flow meter. Pressure transmitters on the bench should use 4-20 mA HART and direct digital output to avoid analog drift.
If you need a paperless recorder for bench validation, Silver Instruments provides a unit with Modbus RTU and USB export. It records flow, pressure, temperature, and totalized mass in one data file. This makes FAT and SAT reports easier for water utilities in the Philippines and Indonesia.
FAQ: Gravimetric Automated Weight System Configurations
What is a gravimetric automated weight system for a flow meter test bench? It is a calibration system that measures liquid mass collected in a tank over time. The mass is compared with the flow meter pulse total or analog output. It gives a direct reference for flow meter accuracy.
Which flow meters can be tested on this type of bench? Electromagnetic, Coriolis, oval gear, turbine, ultrasonic, vortex, and thermal mass flow meters can be tested. The key requirement is a stable liquid or gas circuit and a defined flow range. Silver Automation Instruments supports testing of its own flow meter portfolio on customer benches.
How accurate is a gravimetric bench compared with a master meter bench? A gravimetric bench typically reaches total uncertainty from 0.05 percent to 0.2 percent depending on the scale, diverter, and temperature control. Hybrid systems combine both to reduce cycle time and retain traceability. For custody transfer meters, gravimetric is usually preferred.
What line sizes and flow rates are practical? DN15 to DN150 is the most common range for gravimetric benches. Flow rates commonly run from 0.05 kg/h for low flow Coriolis meters up to 120 m3/h for DN150 water meters. Larger DN200 to DN400 lines usually use master meters or clamp-on ultrasonic references due to cost and space.
What should I send to Silver Automation Instruments for a bench quote? Send us your pressure (bar), temperature (°C), pipe size (DN), flow range, fluid type, viscosity in cP, conductivity in µS/cm, and required uncertainty. Also include the meter output available such as pulse, 4-20 mA HART, or Modbus RTU. You can reach Silver Automation Instruments by Tel: +86-25-68650347, Whatsapp: +86-25-52155837, or WeChat: +86 15365082610.
