What instrument is used to measure underground pipe network leakage?

The commonly used instruments and techniques for measuring underground pipe network leakage are as follows: acoustic leak detector (leak detector). This is the most basic leak detection tool, which locates the leak point by capturing the high-frequency "hissing" sound generated by the leak point.. Its core components include high-sensitivity pickups (ground tone and contact type), a host, and headphones. When operating, place pickups along the pipeline layout area, identify abnormal sounds through headphones, and use "triangulation" or spectral analysis functions to eliminate interference and determine the location of the leak point. Suitable for metal or plastic pipes, but sensitive to environmental noise. When the leakage sound is weak or the environment is noisy, the correlation instrument locates the leakage point by analyzing the "correlation" of the vibration signal of the pipeline. The principle is to install sensors at two points in the pipeline to measure the time delay of vibration signals. When the signals match, the leakage point is located between the two sensors. The host automatically calculates the correlation curve, and the peak position is the leakage point. Suitable for long-distance pipelines or low-noise scenarios. A gas detector (tracer gas detector) is used to detect minor leaks without sound signals by injecting a non-toxic mixture of gas (such as 95% nitrogen+5% hydrogen) to track the leak point. Gas seeps out from the cracks and spreads to the surface, and the hydrogen sensor detects an abnormal increase in ground gas concentration to locate the leak point. Suitable for pipes with good sealing properties such a

How much does an underground pipeline flow meter cost

s plastic pipes, cast iron pipes, or deep pipelines. A thermal imaging camera (infrared thermal imager) uses the temperature difference between water leakage and soil to locate the leakage point. Leakage water causes changes in surface temperature, and thermal imaging captures differences in infrared radiation and converts them into visible images, resulting in abnormal colors in the leakage area. It should be used when there is a significant temperature difference (such as in winter), but it is usually used as an auxiliary measure due to factors such as weather and soil moisture. The pipeline endoscope (video detector) accurately confirms the leakage point at a known approximate location. The flexible probe carries a camera and a head mounted disassembly light into the pipeline, transmitting internal images in real-time. The operator observes signs of leakage such as cracks, corrosion, or loose joints through the screen. Suitable for scenarios that require intuitive verification, but require the pipeline to have inlet conditions. Pressure testing and flow monitoring are used to evaluate the overall leakage situation of the pipeline network. Pressure testing involves pressurizing the isolated pipe section and observing the pressure drop to determine if there is a leak. Flow monitoring: Record non peak water usage flow through flow meters, and abnormal flow may indicate leakage. Both provide basic data for maintenance plans, but cannot accurately locate individual leakage points. In actual testing, it is usually necessary to combine multiple instruments: first, use acoustic detectors and flow monitoring to delineate suspicious areas, then use relevant instruments to accurately locate them, and in complex situations, suppl
